SCZ50-2D伸縮臂吊裝機
（Telescopic Crane Loader）
[ 產品簡介 Product Introduction ]
SCZ50-2D型伸縮臂吊裝機，底盤采用前輪驅動，后輪轉向，剛性懸掛；傳動采用前后各兩檔液力機械傳動變速箱，全液壓動力轉向，制動為氣推油鉗盤式制動；工作裝置為兩節四邊形伸縮臂和一個可旋轉吊臂組成。該機專用于進集裝箱石板材的吊裝作業，也可作為一般吊車使用，可廣泛適用于工廠、碼頭、貨場、林場、建材、倉庫、物流等行業，是一種適應性廣和效率高的裝卸機械。
The SCZ50-2D Telescopic Crane Loader works with front-wheel drive, rear-wheel steering, rigid suspension; adopt total four hydromechanical drive gear-boxes in the back and front as the transmission, hydraulic power steering, caliper disc brake; the working device is composed of two quadrilateral portable telescopic arms and a rotary boom. It is specially used for lift on/off the stone slab container and it can also be used as a normal crane. It is widely available for the factory, dock, goods yard, forestry center, building materials industry, warehouse, logistics and so on. It is a handling machinery of wide application and high efficiency.
[ 主要技術參數 Specifications ]
|
額定起重量 Rated Load |
5000kg | |
|
載荷中心距（輪胎前沿距載荷中心） The Distance of Load Center(Tyre-fore to load center) |
| |
|
主鉤最大起升高度（主吊鉤距地面） Max.Lifting Height of Main Hook(Main hook to ground) |
6250mm | |
|
主鉤最大外伸距（水平）（輪胎前沿距主吊鉤） Max.Outspread of Main Hook(Horizontal)(Tyre-fore to main hook) |
2750mm | |
|
最大行駛速度 Max.Traveling Speed |
25km/h | |
|
最小離地間隙 Min.Ground Clearance |
365mm | |
|
最小轉彎半徑 Min.turning Radius |
6800mm | |
|
爬坡度 Grade Ability |
≥20% | |
|
傾翻角度上/下 The Angle of Lean Up/Down |
24°/22.5° | |
|
輪距 Tread |
1825mm | |
|
軸距 Wheel base |
2998mm | |
|
自重 Deadweight |
13000kg | |
|
整機外形尺寸（長×寬×高） Overall Dimension (L×W×H) |
| |
|
發動機（一拖東方紅） Engine (Yituo Dongfanghong) |
型號 Type |
LR4108G76 |
|
額定功率 Rated power |
74kw | |
|
標定轉速 Rated speed |
2400r/min | |
|
排量 Exhaust |
4.6L | |
|
輪胎 |
前輪 Front wheel |
15.5-25(16PR) |
|
后輪 Rear wheel |
11.00-20(16PR) | |
注：由于技術改進，該數據可能與產品不符，如有誤則以產品為準。
Note:The content and performance will be revised and the products will be improve without notice.
